ZJ-SMT supplies the N1L20522 Panasonic NC board for automated insertion machines in the axial range — the equipment that inserts leaded components into through-hole boards. The board sits in the control cabinet and carries the control logic the machine runs on, so it is the part that goes back in when the original is damaged or stops responding.
Orders come from EMS plants, through-hole assembly factories and independent repair companies that keep Panasonic insertion equipment running, as well as from buyers restocking a maintenance cabinet. Some customers order one board for a machine that is down; others add it to a larger order of parts for the same line.
The board is supplied for Panasonic axial insertion machines. It is the version built for that platform rather than a general-purpose controller, so it is not the part you would order for a placement or inspection machine, even where the cabinets look similar.
Buyers running mixed floors often ask what else can be supplied with it. Alongside insertion machine spares we handle parts for the main smt pick and place machine manufacturers — Panasonic, Yamaha, Fuji, Juki and Samsung among them — so a maintenance order can be built around the machines you actually run.
ZJ-SMT supplies Panasonic SMT and PCB assembly equipment and spare parts to manufacturers worldwide. Our range covers pick-and-place machines, axial and radial insertion equipment, solder paste inspection systems, and feeder spare parts, with both new and used options available. We support bulk orders, and machine condition and availability are confirmed with you before ordering. Whether you are expanding a line, replacing a worn feeder part, or sourcing equipment for a new project, send us your model numbers and our team will come back with a suitable solution and quotation.
The change is a board swap inside the control cabinet, so a technician who normally works on Panasonic equipment can usually complete it in one visit. If you have not changed one before, work through the fitting steps in order and keep the old board until the machine has run a full cycle. Send us photographs of the cabinet if anything looks different from the way it came apart and our team will advise.
Keep it in its protective bag and handle it by the edges only, because static is the main risk to a board that is not fitted to a machine. Store it somewhere dry and away from heat, and do not stack tools or loose parts on top of it. A shelf in the maintenance cabinet is fine as long as nothing heavy can fall onto the bag.
No. This board is supplied for the axial automated insertion machines. Panasonic builds similar-looking boards for other insertion platforms, and they are not interchangeable, so order by the number printed on the original board rather than by appearance. If you are replacing a board on a different machine, send us that number and we will supply the matching part.
Each platform has its own board numbers. This board belongs to the Panasonic axial inserters; the parts we supply for the smt pick and place machine manufacturers' platforms are separate items with their own numbers. Send the numbers you are working with and we will confirm each one against the machine it is going into.
Most orders are for the board alone, because a fault is normally traced to one item. Plants that keep a spares cabinet often restock the parts that wear alongside it — feeder parts, servo drivers and other boards from the same cabinet. Tell us which machine the order is for and we will point out the items that are usually held together.
If two machines are the same model and both use the same board number, the board can be moved between them. Check the number printed on each machine before you rely on that, because a plant that bought its inserters at different times may be running more than one board version. If you are unsure, send us the details from both machines and we will confirm.
