N1L20523 Panasonic NC Board component insertion machine

Product Overview

This is the NC board supplied as a replacement for Panasonic component insertion machines. It handles the numeric control side of the machine's operation, working with the other boards, drivers and motors in the same unit, and it is the part that is changed when a fault is traced to the control electronics rather than to the mechanical side of the inserter.

Because these machines stay in service for many years, the board is nearly always bought for a machine that is already running rather than for a new line. It takes the place of the failed unit in the same position, and a single board is usually all that is needed to get the inserter producing again - this is a replacement part, not a machine, a kit or an upgrade.

It is supplied on its own so a single failed board can be replaced without buying a set, and it comes from the same Panasonic spare-parts stock as the feeders, motors and other boards we supply.

Key Features

• Order by the printed number: the board is identified by the part number on the original unit, so read that number first - it is the one detail that decides whether the replacement is the right one.
• Built for the component insertion platform: this is a board for Panasonic component insertion machines, not for placement, reflow or inspection equipment, so it belongs on the inserter in your line rather than elsewhere on the floor.
• Checked before dispatch: send the machine model, the number you have and the quantity you need, and our team confirms the details with you before the board is packed.
• Ordered with the machine's other spares: feeder parts, nozzles, valves and motors for the same unit can be listed in the same request so one shipment covers the parts your team needs.
• One supplier across the line: plants that also run equipment from pick and place machine manufacturers can source this board and their other Panasonic spares together instead of splitting the order between suppliers.

Specifications

Typical Buyers

Maintenance teams at PCB assembly plants are the most frequent buyers. They order when a fault has been traced to the control electronics of an automated insertion machine and the line is held up waiting on the part.

Spare-parts and purchasing teams buy the board as a planned item, matching the number against the machine before they commit, because a wrong number costs a second stoppage. Repair and service companies that look after Panasonic inserters for other factories use it in breakdown repairs and rebuilds, and industrial distributors keep one or two for the assembly plants they supply.

Smaller workshops, especially those keeping older equipment in service, come to us when a board has to be found quickly and the usual local route has nothing on the shelf.

Applications on the Line

• Mid-shift breakdown: an automated insertion machine stops, the fault is traced to the control board, and the replacement goes in so the machine can return to production without changing anything else.
• Planned shutdown: a board that has been giving intermittent faults is swapped out during a scheduled maintenance window instead of being left to fail in the middle of a run.
• Machine restart: an older Panasonic inserter coming back into service after storage or a plant move often needs its control board checked or replaced before the first production run.
• Mixed-line ordering: factories that also run equipment from smt pick and place machine manufacturers order this board with their other Panasonic spares so a single delivery covers the whole requirement.

Scale & Supply Capability

ZJ-SMT supplies Panasonic SMT and PCB assembly equipment and spare parts to manufacturers worldwide. Our range covers pick-and-place machines, axial and radial insertion equipment, solder paste inspection systems, and feeder spare parts, with both new and used options available. We support bulk orders, and machine condition and availability are confirmed with you before ordering. Whether you are expanding a line, replacing a worn feeder part, or sourcing equipment for a new project, send us your model numbers and our team will come back with a suitable solution and quotation.
