N510002594AA Panasonic Control Unit Y Driver CM602 AI Spare Parts

Product Overview

The control unit Y driver is the board that sits between the machine controller and the Y axis on a Panasonic CM602 AI. It receives the position commands, drives the axis through every production move and reports back so the machine keeps its timing. When the Y axis stops responding, this is usually the unit that puts the axis back under control.

ZJ-SMT supplies it as a straight replacement for the same part number, so it returns to the same position and reconnects to the machine's existing wiring. Buyers are mostly maintenance engineers, spare-parts stores and production managers keeping CM602 AI lines running: one stalled axis stops the whole line and the SMT components behind it wait. Parts for Panasonic machines and for equipment built by other pick and place machine manufacturers come through the same supply channel.

Key Features

• Drop-in replacement — the unit fits the same position as the failed driver and uses the machine's existing connectors, so there is no adapter, no bracket work and no rewiring to organise.
• Fast fault isolation — on a stopped machine, swapping the Y driver is the quickest way to prove whether the fault sits in the drive or further along the axis, before you spend time on a motor or wiring repair.
• Built for control-section duty — this board runs every shift alongside heat, vibration and constant switching, so it is supplied as a production part rather than a bench item.
• Records stay consistent — the replacement carries the same part reference as the unit it replaces, so stock labels, spare-parts lists and maintenance records all keep matching.

Compatibility & Machine Fit

Fit is decided by the number on the unit, not by the machine family alone. A CM602 AI carries several separate control boards, and the Y driver is not interchangeable with the head control board or the SSR board — each sits in its own circuit, so always order against the number printed on the board you are replacing.

It is also worth reading the label on the unit that is actually installed rather than the one in the manual. A machine that has already been through a repair may be running a board that was changed years ago, and the cabinet is the only reliable place to confirm what you have.

Labels fade, too. If the printing on your board is worn or partly illegible, photograph the unit and its connector positions and send them over — the layout and the machine model are usually enough for us to identify the right replacement.

Y-Axis Fault Checks

• Faults that return after a reset — if the Y axis alarms, homes slowly or drifts out of position, and the same fault comes back after a power-down, the drive board is one of the first items to check.
• Motion that holds at low speed but stalls in production — an axis that jogs fine and then lags or stalls during fast moves usually points at the drive stage rather than the mechanics.
• The simple checks first — reseat every connector on the board and look at the axis mechanically before you order anything; a loose plug or a tight coupling mimics a failing drive more often than most teams expect.
• Visible damage — heat marks, discoloration or a swollen component around the drive section are worth a look with a torch before you make the call.
• Intermittent behaviour — if the axis behaves differently when the machine is hot than when it is cold, note what you see and tell us; it helps confirm the right part the first time.

Fitting & Commissioning

1. Power the machine down and follow your own lock-out procedure; give the control section a few minutes to settle before you open the cabinet.
2. Photograph the connectors and the mounting before you unplug anything — a couple of reference shots make reassembly quick.
3. Take the failed unit out, set it aside and note which position it came from.
4. Fit the replacement in the same position, push every connector fully home and refit the mounting screws.
5. Power up, home the Y axis and run a slow test move before you release the machine to normal production.
6. If the fault is still present after the swap, stop and send us the alarm details together with the number on the original board — the cause is likely to be elsewhere on the axis.

Part & Fitting Reference

Scale & Supply Capability

ZJ-SMT supplies Panasonic SMT and PCB assembly equipment and spare parts to manufacturers worldwide. Our range covers pick-and-place machines, axial and radial insertion equipment, solder paste inspection systems, and feeder spare parts, with both new and used options available. We support bulk orders, and machine condition and availability are confirmed with you before ordering. Whether you are expanding a line, replacing a worn feeder part, or sourcing equipment for a new project, send us your model numbers and our team will come back with a suitable solution and quotation.
